TICKET REDEMPTION

NEW

Soccer Safari SpongeBob (Vending & Redemption) SpongeBob, Patrick And Squidward Are On The First Line In This Exciting Skill Game For Kids.

Short url COPY http://www.andamiro.com/games/soccersafariS

INQUIRE
CATEGORY OF QUESTIONS	TYPE OF QUESTIONS
AREA	AREA
COUNTRY	COUNTRY
Your Name (required)	Your Name (required)
Your Email (required)	Your Email (required)
Subject	Subject
Select Parts	Select Parts
Your Message	Your Message
FILE UPLOAD ##1	FILE UPLOAD ##1
FILE UPLOAD ##2	FILE UPLOAD ##2
CAPTCHA	CAPTCHA
NEWS LETTER	NEWS LETTER Yes! I would like to receive ANDAMIRO's newsletter.
CAPTCHA
I agree to the collection and use of personal information.

SUPPORT

Leaflets (2)
Manuals (1)
Document (1)
Trouble shooting
Video List (5)

FEATURES

SpongeBob, Patrick And Squidward Are On The First Line In This Exciting Skill Game For Kids.

The Soccer Safari line includes licensed SpongeBob cabinet packages in both vending and redemption versions.

Like the original Safari game, the SpongeBob vending version dispenses 2”

round capsules or novelty balls and holds up to 200 units. Prizes “self-transport,” rolling down a ramp from

the storage bin to the prize door. Designed for arcades and FECs, the SpongeBob redemption version awards tickets proportional to a player’s score;

it is compatible with card swipe systems and coin or token/paper ticket operations.

Gameplay is the same in all models: the player fires mini soccer balls trying to defeat the moving goalkeeper.

GALLERY

Sorry, this is not available at the moment.

PARTS

동기화 작업중입니다.
페이지를 이동하거나 닫으면 오류가 발생할 수 있습니다.

Total 60Parts

No.	Part name Part picture	Code Info	Part picture	Part Add

PARTS INQUIRY

1	[] AC INPUT DAC-13H	[] AC INPUT MELE0SWI015	Part picture
1	BUTTON SWITCH P&H_0.0.0.203-10	BUTTON SWITCH MZZZ0BUT090	Part picture
2	BEARING F686ZZ	BEARING MZZZ0BEA094	Part picture
1.2	[BEARING] FUSE 10A 0218010.MXP 250V,10A,4PA	[BEARING] FUSE 10A MELE0FUS018	Part picture
3	MOTOR KGC-040-3429C	MOTOR MZZZ0MOT089	Part picture
4	HAND BOLT M4, PKB4 4*10L	HAND BOLT MZZZ0PLA030	Part picture
5	POWER SMPS LRS 150F-12	POWER SMPS MELE0SMP090	Part picture
6	POWER SMPS RS-75-5	POWER SMPS MELE0SMP040	Part picture
7	COIN BOX ASS WITH 6001 SMALL 200198107	COIN BOX ASS WITH 6001 AZZZ0ASS002	Part picture
8	SPONGE_10X1000 4T BLACK	SPONGE_10X1000 4T MPCX0PLA007	Part picture
9	SPEAKER MID 4.5"+TW1/2" 8Ω W-C-100 F BK	SPEAKER MZZZ0SPE021	Part picture
10	CAPSULE HOPPER .	CAPSULE HOPPER MZZZ0HOP075	Part picture
11	STATIC BRUSH L80-9.5-9-0.8P	STATIC BRUSH MZZZ0BRU001	Part picture
1.11	[STATIC BRUSH] SOLENOID SPRING .	[STATIC BRUSH] SOLENOID SPRING MSSF0SPR001	Part picture
2.11	[STATIC BRUSH] SOLENOID CORE	[STATIC BRUSH] SOLENOID CORE MSSF0PRO012	Part picture
12	FLEX_5050_RGB_650_NWP_L_39 T5050 TOP300구 39알	FLEX_5050_RGB_650_NWP_L_39 MELE0LED079	Part picture
1.12	[FLEX_5050_RGB_650_NWP_L_39] SOLENOID SHAFT ASS'Y MSSF0PRO013,014	[FLEX_5050_RGB_650_NWP_L_39] SOLENOID SHAFT ASS'Y ASSF0PRO001	Part picture
13	BALL TRAFFIC JAM SHAFT	BALL TRAFFIC JAM SHAFT MSSF0PRO005	Part picture
14	BEARING BUSHING	BEARING BUSHING MSSF0PRO006	Part picture
15	BEARING FIX WASHER	BEARING FIX WASHER MSSF0PRO007	Part picture
16	PIN	PIN MSSF0PRO011	Part picture
17	GOALKEEPER ACRYL FIX HOLDER	GOALKEEPER ACRYL FIX HOLDER MSSF0PRO009	Part picture
18	BEARING WASHER	BEARING WASHER MSSF0PRO008	Part picture
19	WEIGHT	WEIGHT MSSF0PRO016	Part picture
20	SENSOR_T PCB ASS'Y CODE CHANGE AAV20PCB011	SENSOR_T PCB ASS'Y ASSF0PCB002	Part picture
21	MAIN PCB ASS'Y ADSTAR	MAIN PCB ASS'Y ASSF0PCB001	Part picture
22	PLAYFIELD NUMBER STICKER 일반향/스펀지밥향 공용	PLAYFIELD NUMBER STICKER MSSF0STI001	Part picture
23	MOLD-BALL GROUND .	MOLD-BALL GROUND MSSF0PLA001	Part picture
24	BEARING MF126ZZ	BEARING MZZZ0BEA137	Part picture
25	SOLENOID ASS'Y ASSF0PRO001,MSSF0PRO012,MSSF0SPR001,MELE	SOLENOID ASS'Y ASSF0SOL001	Part picture
26	CPU PCB ASS'Y ADSTAR	CPU PCB ASS'Y ASSF0PCB005	Part picture
27	STATIC OFF SPRAY .	STATIC OFF SPRAY AZZZ0000110	Part picture
28	TIMMING BELT 232MXL,W4.8 RUBBER	TIMMING BELT MZZZ0BEL048	Part picture
29	LED BAR 12V ASS'Y 460MM	LED BAR 12V ASS'Y AZZZ0PCB124	Part picture
1.29	[LED BAR 12V ASS'Y] COIN BOX SMALL 200198107 BLACK	[LED BAR 12V ASS'Y] COIN BOX SMALL MDRE0PLA007	Part picture
30	COIN SELECTOR TW-389	COIN SELECTOR MZZZ0COS052	Part picture
31	TIMMING PULLEY MXL-29	TIMMING PULLEY MZZZ0PLA040	Part picture
32	PLUG CUSHION RUBBER 공진 [KD-96R-9] 6MM	PLUG CUSHION RUBBER MCIR0RUB001	Part picture
33	LED STICK BAR BRK 12MM 90도	LED STICK BAR BRK MELE0000022	Part picture
34	PHOTO INT-1 PCB ASS'Y ANGLE TYPE	PHOTO INT-1 PCB ASS'Y AZZZ0PCB103	Part picture
35	AC INPUT ASS'Y DAC-13H,WITH FUSE10A_2EA	AC INPUT ASS'Y AELE0FUS002	Part picture
36	NOISE FILTER RNS-2010	NOISE FILTER MELE0NOI009	Part picture
1.36	[NOISE FILTER] HANESS CAPSULE HOPPER SSF	[NOISE FILTER] HANESS MZZZ0HAN131	Part picture
2.36	[NOISE FILTER] KEY ASS'Y 6001 6001 ONLY BODY	[NOISE FILTER] KEY ASS'Y 6001 MZZZ0KEY075	Part picture
37	KEY ASS'Y 7001 7001 ONLY BODY	KEY ASS'Y 7001 MZZZ0KEY076	Part picture
38	KEY ONLY 7001 2EA 1SET_WITH RING	KEY ONLY 7001 MZZZ0KEY035	Part picture
39	KEY ONLY 6001 2EA 1SET _WITH RING	KEY ONLY 6001 MZZZ0KEY014	Part picture
40	ROCKER SWITCH R595KDF	ROCKER SWITCH MELE0SWI021	Part picture
41	PUSH BUTTON SWITCH DS-412R ROSH	PUSH BUTTON SWITCH MELE0PUS006	Part picture
42	POWER SMPS LRS 150F_24	POWER SMPS MELE0SMP085	Part picture
43	VOLUME PCB ASS'Y 1 VOLUME	VOLUME PCB ASS'Y AHM20PCB016	Part picture
44	SOL FET 2CH PCB ASS'Y V2	SOL FET 2CH PCB ASS'Y AZZZ0PCB203	Part picture
45	COUNTER OA127CL W/2P CONNECTOR_20CM WIRE	COUNTER MZZZ0COU002	Part picture
46	VOLUME KNOB CAP BLUE	VOLUME KNOB MELE0VOL007	Part picture
47	FND PCB ASS'Y 2941-2(STRAIGHT)	FND PCB ASS'Y AFND0PCB003	Part picture
48	TERMINAL BLOCK KTB1-020 6P UL_CE	TERMINAL BLOCK MELE0TEB001	Part picture
49	BALL COLOR_SAFARI6종 1SET 12PCS 노랑 하늘 연두 분홍 보라 파랑	BALL COLOR_SAFARI6종 1SET 12PCS AZZZ0ASS116	Part picture
50	MOTOR KGE-3448-050-12V_1/204 F-TYPE	MOTOR MZZZ0MOT072	Part picture
51	SENSOR_R PCB ASS'Y .	SENSOR_R PCB ASS'Y MEIF0PAR014	Part picture
52	FLEX_3528_GREEN_450_NWP_L_27 T3528 TOP300구 27알	FLEX_3528_GREEN_450_NWP_L_27 MELE0LED062	Part picture
